SS Railing Steel Pipes Weight Chart List by PS Steel

What is a Steel Pipe Weight Chart?

Definition and Importance

At PS Steel, we believe that the success of any project depends on proper material selection and accurate calculations.
A Steel Pipe Weight Chart is a technical table that provides the exact weight of pipes for different diameters, thicknesses, and lengths.
It is extremely useful across industries such as:

• Construction

• Manufacturing

• Water supply

• Oil and gas

• Industrial plants

Applications in Construction and Manufacturing

Knowing the pipe’s weight is essential because it determines:

• The load a structure will bear

• The crane capacity required

• The transportation and handling costs

Our customers use this chart to select the right grade and size for:

• Steel structures

• Railings

• Industrial pipeline projects

Why Accurate Weight Calculation is Important

Accurate weight calculations help in:

• Increasing safety and efficiency

• Ensuring ease of installation

• Preventing material wastage

At PS Steel, every pipe is tested as per IS and ASTM standards to ensure both accurate weight and superior quality.

Steel Pipe Weight Chart Specifications

Pipe Dimensions and Standards

• Nominal Pipe Size (NPS): Indicates the pipe’s nominal outer diameter (OD).

• Outside Diameter (OD): Measured from the pipe’s outer surface.

• Wall Thickness: Determines pipe weight and pressure capacity.

• Standard Lengths: 6 meters (20 feet) and 12 meters (40 feet).

Schedule Classification

At PS Steel, we offer pipes in multiple schedule classes:

• Schedule: 5, 10, 20, 30, 40, 80, 120, 160

• Standard Strength: STD (Standard), XS (Extra Strong), XXS (Double Extra Strong)

Each schedule defines the wall thickness and pressure tolerance.

Complete Weight Chart List of Steel Pipes

Mild Steel (MS) Pipe Weight Chart

MS pipes are known for strength and affordability.
Classes include:

• A-Class (Light): For low-pressure applications

• B-Class (Medium): For general industrial use

• C-Class (Heavy): For high-pressure and structural use

All MS pipes are manufactured as per IS 1239 (Part-1) standards.

Stainless Steel (SS) Pipe Weight Chart

At PS Steel, we supply SS pipes in grades:

• SS 304: General use and railings

• SS 316: Marine and chemical environments

• SS 310/321: High-temperature applications

• SS 347: Excellent corrosion resistance

All SS pipes are certified as per ASTM A312.

Carbon Steel Pipe Weight Chart

• Available in Schedule 40 and Schedule 80

• Ideal for high-pressure plumbing

• Exact weight charts (per foot and per meter) are available in our catalog.

Large Diameter Steel Pipe Weights

• Range: 8 inches to 24 inches

• Types: ERW (Electric Resistance Welded) and Seamless

• Used for heavy structural and industrial applications

Steel Pipe Weight Calculation Methods

Weight Calculation Formula

Basic Formula:
Weight = π × [(OD/2)² - (OD/2 - t)²] × Length × Density

Simplified Formula (lbs/ft):
Weight = (OD - t) × t × 10.69

Metric Formula (kg):
Weight = 0.02466 × t × (OD - t) × L

Steel Pipe Weight Calculator

At PS Steel, we provide an Online Weight Calculator Tool.

• Enter the OD, thickness, and length.

• Get instant accurate results.

• Also available: Excel Template with automatic conversions between kg/m and lbs/ft.

Steel Pipe Weight Charts by Application

Construction Industry

• Building frameworks and structural columns

• Water supply pipelines

• HVAC (Heating, Ventilation, and Air Conditioning) systems

Industrial Applications

• Oil and gas pipelines

• Chemical process lines

• Food and beverage production lines

Manufacturing Specifications

All PS Steel products comply with:

• Jindal and Tata Steel quality standards

• International norms for easy comparison

Downloadable Steel Pipe Weight Charts

PDF Weight Chart Download

You can download:
